Product description
Specification


System



Physical


Operating System:  Android 8.1 Dimension:  207*84*20mm(1)
CPU:  Octa-core 2.0GHz Weight:  370g (Including Battery)(1)
Memory: 4GB RAM+64 ROM Operating Temperature:  -10 ℃ ~ +60 ℃
External Storage: Micro SD, up to 128G Storage Temperature:  -30 ℃ ~ +70 ℃
Display: 5'' sunlight-readablecapacitive touch screen Humidity:  5% ~ 95%
Resolution: 720*1280 Dustproof & Waterproof:  IP68
Camera:  5MP Front , 13MP Rear Shock:  1.5m Drop Onto Concrete(6 Sides)
Flash Light:  High-Brightness LED Flash Vibration:  MIL-STD-810G,FIG 514.6C-1

GNSS



Electrical


Signal Tracking:  GPS, BDS,GLONASS Battery:  7000mAh/3.8V

Communication

  Working Time(Typical): 14hours(2)
Cellular Mode:  Dual SIM Dual Standby Charging Time:  <4 Hours (Fast Charge)
SIM Slot:  2 Micro SIM Slots

Operations


SIM1 & SIM2: FDD-LTE B1/B3/B5/B7/B8 Power Button:  Power on/off, reboot, forced restart
TDD-LTE B38/B39/B40/B41 Menu Key: Shows applications that was used recently
TDSCDMA B34/B39 Home Key:  Return to home screen
WCDMA B1/B2/B5/B8 Back Key:  Return to previous screen
GSM B2/B3/B5/B8 APP Key: Quick start Nuwa application
CDMA1x/CDMA2000 BC0/BC1 ENTER Key: Execute the function of confirming in Nuwa application
Wi-Fi: IEEE 802.11 a/b/g/n/ac 2.4G&5G aA Key: Caps lock
Bluetooth:  BT4.1 (BLE) FN Key:  Switch between numbers & characters
NFC: Protocol of ISO14443A/B, ISO15693,
Readable distance 0~5cm
Blue Positioning Key: Start measurement in the Survey and
Stakeout interface of Nuwa application
USB: USB Type-C, Supports OTG Yellow Bulb Key:                     Control the screen on and off
Sensors:  G-Sensor, Compass, Light-Sensor, Gyro

Note:
(1) The actual size/weight may vary depending on the manufacturing process and measurement method.
(2) The working time of the battery is related to the working environment, working temperature and battery life.
